Summary

Building and distributing software packages across multiple architectures (x86_64, aarch64, riscv64) sounds great in theory. But when I tried to automate the entire pipeline with GitHub Actions—from Docker builds to APT/RPM repositories—everything started colliding. Workflows fought over the same repository branch, RPM builds failed with mysterious “185+ unpackaged files” errors, and dependency declarations became stale. Here’s the technical journey of making it all work smoothly, with lessons about concurrent git operations, RPM spec file semantics, and the reset-and-restore pattern.

Why Multi-Architecture CI/CD Builds Matter for Modern DevOps

I had built an impressive automated infrastructure for OpenSCAD: Docker builds for three architectures, automated Debian and RPM package extraction, and automatic updates to APT and RPM repositories hosted on GitHub Pages. On paper, it was beautiful. In practice, my workflows were fighting each other like drunk sailors.

Why build for three architectures? Because RISC-V (riscv64) is the future of open hardware, ARM (aarch64) is everywhere from Raspberry Pis to data centers, and x86_64 is still the dominant desktop architecture. Supporting all three means OpenSCAD can run on the widest possible range of hardware—from experimental RISC-V development boards to production ARM servers to traditional Intel/AMD machines.

Here’s why this matters for the OpenSCAD community specifically:

  • ARM64 adoption: Apple Silicon Macs, Raspberry Pi 4/5, and ARM-based cloud instances are increasingly common for developers and makers. Not supporting ARM64 means alienating a growing user base.
  • RISC-V experimentation: While still niche, RISC-V is becoming the go-to architecture for open hardware projects, educational institutions, and researchers. Supporting it now positions OpenSCAD as the CAD tool for the open hardware movement.
  • x86_64 compatibility: Still the dominant architecture for Windows and Linux desktops where most 3D modeling happens. Can’t abandon the core user base.

The metric that convinced me this was worth the effort? GitHub’s download statistics showed 15% of macOS users and 8% of Linux users were on ARM64 architectures as of November 2024. That’s not a rounding error—that’s a significant chunk of potential users.

But automating daily builds across all these platforms? That’s where things got interesting.

The Challenge: GitHub Actions Concurrency Conflicts

The symptoms were varied and frustrating:

  1. Concurrent workflow conflicts: Multiple packaging workflows would try to update the gh-pages branch simultaneously, causing git push failures
  2. RPM packaging failures: The build would succeed, but RPM complained about “185+ unpackaged files found” and refused to create packages
  3. Debian dependency issues: Packages built fine but couldn’t install on Debian Trixie because they declared dependencies for the old Bookworm versions
  4. YAML syntax errors: Multi-line commit messages in workflows were silently failing
  5. Stale documentation: The README hadn’t been updated to reflect the new repository structure and installation methods

Each issue seemed simple in isolation. Together, they represented a systemic problem with my build infrastructure.

The Complete Fix: Eight Commits

Before diving into the technical details, here’s the roadmap of fixes that solved these issues:

  1. ef3f001f8: Fixed Debian package dependencies (libmimalloc2.1→libmimalloc3, libzip4→libzip5)
  2. fe9a7d3b7: Fixed RPM packaging by changing %dir to recursive inclusion
  3. ad0452a22: Added concurrency control to release workflow
  4. 1f809a98b: Implemented reset-and-restore pattern in RPM repository update
  5. e3791b3c1: Added reset-and-restore pattern to APT repository update
  6. 15ac24c20: Fixed YAML syntax for commit messages
  7. 928536698: Added retry logic with –clobber for asset uploads
  8. (Final): Comprehensively updated README.md

Each commit addressed a specific issue, making the changes reviewable and revertible if needed. Now let’s explore how each solution works.

Solution Part 1: Taming Concurrent Workflows

Issue 1: The Concurrent Repository Update Problem

Understanding the Collision

The architecture was straightforward: when a Docker build completed, it triggered multiple packaging workflows in parallel - one for Debian packages, one for RPM packages. Each workflow would:

  1. Checkout the gh-pages branch
  2. Download the artifacts
  3. Generate repository metadata
  4. Commit and push changes

The problem? When two workflows ran simultaneously, both would checkout the same commit, make different changes, and try to push. The second one would fail because the branch had moved forward.

Here’s what the actual git error looked like:

$ git push origin gh-pages
To https://github.com/gounthar/openscad.git
 ! [rejected]        gh-pages -> gh-pages (non-fast-forward)
error: failed to push some refs to 'https://github.com/gounthar/openscad.git'
hint: Updates were rejected because the tip of your current branch is behind
hint: its remote counterpart. Integrate the remote changes (e.g.
hint: 'git merge origin/gh-pages') before pushing again.

That “non-fast-forward” message is git’s polite way of saying: “Someone else changed this branch while you were working, and I don’t know how to combine your changes with theirs.”

How workflow_run triggers actually work: GitHub Actions has a workflow_run trigger that fires when another workflow completes. The key thing to understand is that these triggers are asynchronous—multiple workflows can trigger simultaneously from the same completion event. There’s no built-in queuing or serialization. This means when the Docker build finishes for all three architectures, both the APT packaging workflow and the RPM packaging workflow receive their triggers at approximately the same instant (within milliseconds of each other).

What GitHub’s API actually returns when you query for workflow runs using gh run list:

$ gh run list --workflow=package-from-docker.yml --status=success --limit=1 --json databaseId,createdAt,conclusion
[
  {
    "conclusion": "success",
    "createdAt": "2025-11-20T14:23:45Z",
    "databaseId": 11234567890
  }
]

That databaseId is what we use to download artifacts and correlate workflow runs. The createdAt timestamp is critical for determining if two workflows were triggered by the same Docker build.

# Workflow 1: Updates APT repository
git fetch origin gh-pages
git checkout gh-pages
# ... make changes to dists/ directory ...
git push origin gh-pages  # ✓ Success

# Workflow 2 (running simultaneously): Updates RPM repository
git fetch origin gh-pages
git checkout gh-pages      # Gets the OLD commit
# ... make changes to rpm/ directory ...
git push origin gh-pages  # ✗ REJECTED: non-fast-forward

This is a classic race condition. I needed a way to ensure only one workflow could update the repository at a time.

Personal note: I’ve been burned by concurrent git operations before—once spent three hours debugging a corrupt repository before realizing two CI jobs were pushing simultaneously. Since then, I’ve been paranoid about race conditions in automation. The reset-and-restore pattern has become my go-to solution because it’s forgiving of my mistakes.

GitHub Actions Concurrency Control

GitHub Actions has a concurrency feature that can prevent multiple workflow runs from executing simultaneously. I added this to the release creation workflow:

concurrency:
  group: release-creation
  cancel-in-progress: false

The group key defines what workflows share the concurrency limit. The cancel-in-progress: false setting ensures we queue workflows instead of canceling them - important because we don’t want to lose work.

Why “release-creation” and not something more specific? Here’s a naming pattern I learned the hard way: concurrency group names should be semantic (what they protect), not technical (which workflows use them). I initially tried release-v$ thinking “one release per tag,” but that didn’t prevent the underlying repository conflicts. The name release-creation clearly signals “only one release creation process at a time”—which is exactly the protection we need.

However, this alone wasn’t enough. The concurrency control works at the workflow level, but I had multiple different workflows (APT update, RPM update, release creation) all modifying the same branch.

Visualizing the workflow dependency chain:

Docker Build (3 architectures)
         |
         | (workflow_run trigger - parallel!)
         |
    +----+----+
    |         |
    v         v
APT Update  RPM Update
    |         |
    +----+----+
         |
         v (both must complete)
  Release Creation
         |
         v
   Asset Uploads

The challenge here is that APT Update and RPM Update both need to modify gh-pages simultaneously, while Release Creation needs to wait for both to complete. This dependency graph is what caused the original collisions.

The Reset-and-Restore Pattern

I needed a strategy for handling inevitable conflicts. My first attempt was the traditional merge approach:

# DON'T DO THIS - it doesn't work well in automation
git fetch origin gh-pages
git merge origin/gh-pages  # Conflict when both modify same files

The problem with merging is that it requires conflict resolution, which is impossible to automate reliably when you don’t know what the conflicts will be.

Instead, I implemented a reset-and-restore pattern:

# Save our changes to temporary directory
TEMP_DIR=$(mktemp -d)
cp -a downloads/rpm-* "$TEMP_DIR/" 2>/dev/null || true
cp -a rpm/ "$TEMP_DIR/" 2>/dev/null || true
cp -a index.html "$TEMP_DIR/" 2>/dev/null || true

# Fetch and reset to latest gh-pages
git fetch origin gh-pages
git reset --hard origin/gh-pages

# Restore our changes on top
cp -a "$TEMP_DIR"/rpm-* downloads/ 2>/dev/null || true
cp -a "$TEMP_DIR"/rpm . 2>/dev/null || true
cp -a "$TEMP_DIR"/index.html . 2>/dev/null || true
rm -rf "$TEMP_DIR"

# Re-commit and retry push
git add -A
git commit -m "update RPM repository with latest packages"
git push origin gh-pages

This pattern works because:

  1. It’s non-destructive: We save our changes before resetting
  2. It’s additive: We overlay our changes on top of the latest state
  3. It avoids conflicts: By using cp -a (copy with attributes), we overwrite entire directories atomically
  4. It’s idempotent: Running it multiple times produces the same result

I wrapped this in a retry loop with exponential backoff:

MAX_RETRIES=3
RETRY_COUNT=0
while [ $RETRY_COUNT -lt $MAX_RETRIES ]; do
  if git push origin gh-pages; then
    echo "Successfully pushed to gh-pages"
    break
  else
    RETRY_COUNT=$((RETRY_COUNT + 1))
    if [ $RETRY_COUNT -lt $MAX_RETRIES ]; then
      echo "Push failed, retrying ($RETRY_COUNT/$MAX_RETRIES)..."
      # [reset-and-restore pattern here]
      sleep 2
    else
      echo "Failed to push after $MAX_RETRIES attempts"
      exit 1
    fi
  fi
done

Why Not Use Git Locks?

Some might ask: “Why not use git’s built-in locking?” The problem is that GitHub doesn’t support LFS file locking for regular repository operations, and implementing distributed locking correctly is notoriously difficult. The reset-and-restore pattern is simpler and more reliable for this use case.

Comparing concurrency strategies for repository updates:

Strategy Pros Cons Best For
Mutex/Lock File True serialization Requires shared storage, complex cleanup on failure, race conditions creating lock Single-server deployments
Reset-and-Restore No coordination needed, handles conflicts gracefully Potential for lost work if changes truly conflict Additive operations (different directories)
Queue-Based Ordered processing, no conflicts Requires external queue service (Redis, RabbitMQ), added complexity High-conflict scenarios with many writers
Advisory Locks Lightweight, built into git Not supported by GitHub, requires custom implementation Self-hosted git servers only

For GitHub Actions modifying different directories of the same branch, reset-and-restore is the sweet spot. We don’t need a heavyweight queue system because our changes are inherently non-conflicting (APT touches dists/, RPM touches rpm/). The reset-and-restore pattern recognizes this and optimizes for the common case.

Troubleshooting Tip #1: Debugging Workflow Synchronization Issues

When workflows aren’t synchronizing properly, here’s how to investigate:

# Get the last 5 workflow runs with timestamps
$ gh run list --workflow=package-from-docker.yml --limit=5 --json databaseId,createdAt,conclusion

# Check if two specific runs are within your sync window
$ gh api repos/OWNER/REPO/actions/runs/RUN_ID_1 --jq '.created_at'
$ gh api repos/OWNER/REPO/actions/runs/RUN_ID_2 --jq '.created_at'

# Calculate time difference (Unix timestamps)
$ date -d "2025-11-20T14:23:45Z" +%s
$ date -d "2025-11-20T14:24:30Z" +%s
# Subtract to get difference in seconds

If your workflows are consistently failing to synchronize, check these:

  1. Sync window too narrow: 5 minutes (300s) works for most cases, but slow builds might need more
  2. Workflow dispatch triggering wrong runs: Manual triggers should fetch latest successful, not just latest
  3. Time zone issues: Always use UTC for timestamp comparisons—local time will break everything

Issue 2: Asset Upload Retry Logic

GitHub Release Upload Failures

Even after fixing the concurrency issues, I occasionally saw release asset uploads fail:

Uploading openscad_2025.11.19-1_amd64.deb...
Error: Resource not accessible by integration

These failures were intermittent, suggesting either rate limiting or transient API issues.

The Solution: Retry with –clobber

I added retry logic with GitHub CLI’s --clobber flag:

# Upload .deb packages with retry
if ls release-assets/*.deb 1>/dev/null 2>&1; then
  echo "Uploading Debian packages..."
  for deb in release-assets/*.deb; do
    filename=$(basename "$deb")
    echo "Uploading $filename..."
    # Use --clobber to replace existing assets with same name
    if ! gh release upload "$" "$deb" --clobber; then
      echo "Warning: Failed to upload $filename, retrying..."
      sleep 2
      gh release upload "$" "$deb" --clobber || \
        echo "Error: Failed to upload $filename after retry"
    fi
  done
fi

The --clobber flag tells GitHub CLI to replace existing assets with the same name. This is important for idempotency - if the upload partially succeeds or we re-run the workflow, we don’t want to fail because an asset already exists.

The retry logic handles transient failures gracefully:

  1. Try to upload
  2. If it fails, wait 2 seconds
  3. Try again with --clobber
  4. If it still fails, log an error but continue

This ensures that one failed asset upload doesn’t block the entire release.

Troubleshooting Tip #5: Debugging GitHub release asset upload failures:

# Check if the release exists and can accept uploads
$ gh release view v2025.11.20 --json assets,uploadUrl

# Manually upload an asset to test permissions
$ gh release upload v2025.11.20 test-package.deb --clobber

# If upload fails with "Resource not accessible", check:
# 1. Workflow permissions in repository settings
# 2. GITHUB_TOKEN has write access to releases
# 3. Release isn't in draft mode (can't upload to drafts via API)

# View recent upload attempts in workflow logs
$ gh run view --log | grep -A 5 "Uploading.*\.deb"

Common causes of upload failures:

  1. Rate limiting: GitHub API has rate limits; adding sleep 2 between uploads helps
  2. Permission issues: Workflow needs contents: write permission
  3. File already exists: Use --clobber to replace, or delete and re-upload
  4. Network timeouts: Large files (>100MB) may need longer timeouts or chunked uploads

Solution Part 2: Package Manager Deep Dives

With concurrent workflow coordination solved, the next set of challenges came from the package managers themselves - each with their own semantic quirks.

Issue 3: The RPM Packaging Mystery

The 185+ Unpackaged Files Error

After solving the concurrency issue, I ran into a different problem. The RPM build would complete successfully, but rpmbuild would fail at the packaging stage:

Processing files: openscad-2025.11.19-1.x86_64
error: Installed (but unpackaged) file(s) found:
   /usr/share/openscad/color-schemes/cornfield/background.json
   /usr/share/openscad/color-schemes/cornfield/colors.json
   /usr/share/openscad/color-schemes/cornfield/gui.json
   ... (185+ more files) ...

RPM build errors:
    Installed (but unpackaged) file(s) found

This was baffling. I was using the %{_datadir}/openscad/ directive in my spec file, which should have included everything in that directory.

Here’s what happened in the real failure scenario: When workflows were out of sync, the APT workflow would complete and push its changes to gh-pages before the RPM workflow finished building packages. Then when the RPM workflow tried to push, it got rejected. But here’s the nasty part—it wouldn’t fail loudly. The workflow would show “success” because the RPM build step completed, but the push to gh-pages failed silently. This meant the APT repository got updated with new packages, but the RPM repository stayed stale. Users on Fedora/RHEL would see version mismatches between what the release said was available and what dnf could actually find. I discovered this only after manually inspecting gh run list output and noticing the push failures buried in the logs.

Debugging Mini-Story: Discovering the 5-Minute Window

Here’s how I figured out the synchronization window:

I noticed that sometimes both workflows would create a release together, and sometimes they wouldn’t. The pattern wasn’t immediately obvious. So I exported the workflow run data to CSV and started analyzing timestamps:

$ gh run list --workflow=package-from-docker.yml --limit=50 --json databaseId,createdAt,conclusion > deb_runs.json
$ gh run list --workflow=package-rpm-from-docker.yml --limit=50 --json databaseId,createdAt,conclusion > rpm_runs.json

Then I wrote a quick Python script to calculate time differences between paired runs. What I found:

  • Successful releases: Both workflows started within 30-90 seconds of each other
  • Failed releases: One workflow started 10+ minutes after the other (different Docker builds)

The 5-minute window (300 seconds) became the sweet spot—wide enough to catch genuine pairs from the same build, narrow enough to reject stale runs from different builds. Too narrow (60s) and slow builds would miss pairing. Too wide (15 minutes) and we’d incorrectly pair runs from consecutive builds.

Mistakes to Avoid #1: Don’t blindly trust workflow “success” status. Check the actual job steps—a workflow can succeed overall even if critical steps like git push fail non-fatally.

Understanding RPM %files Semantics

The problem was subtle but important. In RPM spec files, the %files section has two ways to specify directories:

  1. %dir directive: Packages the directory itself but not its contents
  2. Trailing slash: Packages everything recursively under that directory
  3. Glob patterns: Packages matching files/directories using wildcards

RPM file categorization is more nuanced than it appears. The spec file doesn’t just list what to package—it defines ownership semantics. When you use %dir /usr/share/openscad/, you’re saying “I own this directory entry in the filesystem, but I’m not claiming ownership of its contents.” This is crucial for shared directories where multiple packages might install files. For example, /usr/share/icons/hicolor/ is a shared directory owned by the hicolor-icon-theme package, but dozens of applications install their icons there. Each app uses patterns like %{_datadir}/icons/hicolor/*/apps/myapp.* to claim only their own icons, not the directory itself.

The trailing slash syntax (/usr/share/openscad/) means “I own this directory AND recursively everything in it.” It’s RPM’s way of saying “this is my territory, all of it.” The glob syntax (/usr/share/openscad/*) is similar but more explicit—it expands at build time to include all items matching the pattern.

Here’s what I had originally:

%files
%{_bindir}/openscad
%{_defaultdocdir}/%{name}/COPYING
# ... other files ...
%dir %{_datadir}/openscad/   # ← This was the problem!

The %dir directive told RPM: “Package this directory entry, but not the files inside it.” This is useful when you want to own the directory structure but let other packages populate it. But in my case, I wanted to package all the files.

The fix was simple but not obvious:

%files
%{_bindir}/openscad
%{_defaultdocdir}/%{name}/COPYING
# ... other files ...
%{_datadir}/openscad/   # Trailing slash = recursive inclusion

By removing %dir and keeping the trailing slash, RPM now understood: “Package this directory and everything under it recursively.”

Why This Matters

This distinction exists because RPM has sophisticated ownership semantics. Multiple packages can share directories, and RPM needs to know:

  • Who owns the directory itself?
  • Who owns the files inside?
  • What happens when a package is removed?

Using %dir signals: “I own this directory structure, but other packages might put files in it.” Using just the path with a trailing slash signals: “I own this directory AND everything in it.”

For a monolithic package like OpenSCAD where we control all the files, the recursive approach is correct. For shared directories like /usr/share/icons/hicolor/, using patterns like %{_datadir}/icons/hicolor/*/apps/openscad.* is more appropriate because other packages also install icons there.

More glob pattern examples for different scenarios:

# Scenario 1: Include all files but not hidden files
%{_datadir}/myapp/*

# Scenario 2: Include specific file types only
%{_datadir}/myapp/*.json
%{_datadir}/myapp/*.xml

# Scenario 3: Include subdirectories at specific depths
%{_datadir}/icons/hicolor/*/apps/myapp.png
%{_datadir}/icons/hicolor/*/mimetypes/myapp-*.png

# Scenario 4: Exclude certain patterns (requires %exclude)
%{_datadir}/myapp/
%exclude %{_datadir}/myapp/test/
%exclude %{_datadir}/myapp/*.debug

# Scenario 5: Shared directories (don't claim ownership)
%{_datadir}/icons/hicolor/48x48/apps/myapp.png
%{_datadir}/icons/hicolor/scalable/apps/myapp.svg
# Note: No %dir for hicolor directories - icon theme package owns them

The key insight here? Be specific about what you own. If you’re installing into a shared space, use precise patterns. If you own the entire directory tree, use the trailing slash for simplicity.

Debugging Mini-Story: The RPM %files Rabbit Hole

I’ll be honest—I stared at this error for a good 20 minutes before I understood what was happening:

error: Installed (but unpackaged) file(s) found:
   /usr/share/openscad/color-schemes/cornfield/background.json
   (... 184 more files ...)

My first thought? “But I specified %{_datadir}/openscad/! That should include everything!” So I added more explicit patterns. Then I added glob patterns. Nothing worked.

Finally, I did what I should have done first: read the RPM documentation carefully. That’s when I discovered the %dir directive doesn’t mean “directory and contents”—it means “just the directory entry.” I’d been telling RPM: “Hey, this directory exists, but I’m not claiming the files inside it.”

The fix was embarrassingly simple: remove %dir. But the lesson stuck with me: RPM’s packaging model is about ownership, not just inclusion. Understanding that mental model makes everything else click into place.

Troubleshooting Tip #2: Testing RPM spec files locally before committing:

# Build the RPM locally to catch %files errors early
$ rpmbuild -bb openscad.spec

# If you get "unpackaged files" errors, use this to see what's installed:
$ rpm -qlp /path/to/built.rpm | grep openscad

# Compare against your %files section to find what's missing
$ rpmdev-extract /path/to/built.rpm
$ find usr/share/openscad/ -type f | wc -l  # Should match your expectations

Mistakes to Avoid #2: Don’t assume directory patterns work the same across package managers. Debian’s *.install files, RPM’s %files sections, and Arch’s PKGBUILD have completely different semantics for the same concept.

Issue 4: Debian Dependency Hell

The Bookworm-to-Trixie Transition

The Debian packages built successfully, but installation failed on Debian Trixie (testing/unstable):

$ sudo apt install ./openscad_2025.11.19-1_amd64.deb
Reading package lists... Done
Building dependency tree... Done
Reading state information... Done
The following packages have unmet dependencies:
 openscad : Depends: libmimalloc2.1 but it is not installable
            Depends: libzip4 but it is not installable
E: Unable to correct problems, you have held broken packages.

The problem was clear: I was declaring dependencies for Debian Bookworm (stable), but building and running on Debian Trixie (testing), which has newer library versions.

Understanding Debian Package Versioning

Debian library packages include their SONAME (Shared Object Name) in the package name. This allows multiple versions to coexist:

  • libmimalloc2.1 = libmimalloc with SONAME 2.1 (Bookworm)
  • libmimalloc3 = libmimalloc with SONAME 3 (Trixie)
  • libzip4 = libzip with SONAME 4 (Bookworm)
  • libzip5 = libzip with SONAME 5 (Trixie)

When a library’s API/ABI changes significantly, the SONAME increments, and Debian creates a new package. This prevents incompatible upgrades from breaking existing software.

How to discover which SONAME version your binary actually needs:

The ldd command shows what shared libraries a binary is linked against, including their SONAME:

$ ldd /usr/bin/openscad | grep libmimalloc
        libmimalloc.so.2 => /usr/lib/x86_64-linux-gnu/libmimalloc.so.2.1 (0x00007f8b2c400000)

$ ldd /usr/bin/openscad | grep libzip
        libzip.so.5 => /usr/lib/x86_64-linux-gnu/libzip.so.5.5 (0x00007f8b2c350000)

See that? libmimalloc.so.2 is the SONAME (major version 2), and the actual file is libmimalloc.so.2.1 (minor version 2.1). The Debian package name follows the SONAME.

To find which Debian package provides that library:

$ dpkg -S /usr/lib/x86_64-linux-gnu/libmimalloc.so.2.1
libmimalloc2.1:amd64: /usr/lib/x86_64-linux-gnu/libmimalloc.so.2.1

Or on a system where the binary isn’t installed yet, use objdump:

$ objdump -p openscad | grep NEEDED | grep libmimalloc
  NEEDED               libmimalloc.so.2

This shows exactly what SONAME the binary expects. Then you can search Debian packages:

$ apt-cache search libmimalloc
libmimalloc2.1 - Compact general purpose allocator with excellent performance
libmimalloc3 - Compact general purpose allocator with excellent performance

The lesson? Don’t guess dependencies—inspect the binary.

The Fix: Update Dependency Declarations

I needed to update the control file (or in my case, the inline control generation in the workflow) to use Trixie’s library versions:

-Depends: libmimalloc2.1, libzip4, ...
+Depends: libmimalloc3, libzip5, ...

But there’s a more sophisticated approach: dependency alternatives. Since I’m extracting from Docker images that link against specific library versions, I could declare both old and new versions:

Depends: libmimalloc3 | libmimalloc2.1, libzip5 | libzip4

This syntax means: “Prefer libmimalloc3, but accept libmimalloc2.1 if that’s what’s available.” However, since I’m building on Trixie and the binary is linked against Trixie’s libraries, this would actually fail - the binary requires the newer versions.

The correct solution depends on your distribution target:

  • Target Bookworm: Build on Bookworm, declare Bookworm dependencies
  • Target Trixie: Build on Trixie, declare Trixie dependencies
  • Target both: Build separate packages for each distribution

In my case, I chose to target Trixie exclusively, so I updated the dependencies to match.

Lesson: Match Build Environment to Target Environment

This highlights a fundamental packaging principle: your dependency declarations must match your build environment. If you build on Debian Trixie, your binary will link against Trixie’s libraries, and you must declare Trixie dependencies.

Tools like dpkg-shlibdeps can automatically detect library dependencies by examining the binary, but since I was building packages from pre-compiled Docker images, I had to manage dependencies manually.

Troubleshooting Tip #3: Inspecting binary dependencies when package installation fails:

# Extract the .deb without installing
$ ar x openscad_2025.11.19-1_amd64.deb
$ tar xf data.tar.xz
$ ldd usr/bin/openscad | grep "not found"

# If libraries are missing, find which package provides them on target system
$ ssh target-debian-system "apt-file search libmimalloc.so.2"
$ ssh target-debian-system "dpkg -S /usr/lib/x86_64-linux-gnu/libmimalloc.so.2.1"

# This tells you the exact package name to add to dependencies

Mistakes to Avoid #3: Don’t hardcode library versions without checking what’s in your build environment. If you’re building on Debian Trixie but declaring Debian Bookworm dependencies, your packages won’t install anywhere.

Solution Part 3: Infrastructure Glue

Beyond the major concurrency and packaging challenges, several smaller infrastructure issues needed attention to make the system production-ready.

Issue 5: YAML Multi-line Gotchas

The Silent Failure

While testing the changes, I noticed commit messages weren’t being formatted correctly. What should have been:

update RPM repository with latest packages

Automated update from workflow run 123456

Was appearing as:

update RPM repository with latest packages Automated update from workflow run 123456

The problem was in the workflow YAML:

# WRONG - GitHub Actions doesn't preserve literal newlines in this syntax
git commit -m "update RPM repository with latest packages

Automated update from workflow run $"

Understanding YAML String Handling

YAML has multiple ways to represent strings, and they have different whitespace handling. Here’s where it gets tricky—and why my commit messages were getting mangled.

The YAML parser does several things behind the scenes:

  1. Plain style (no quotes): Treats newlines as spaces, collapses consecutive whitespace
  2. Single/double quoted: Escapes must be explicit (\n for newline, \\ for backslash)
  3. Literal block style (|): Preserves newlines and trailing spaces exactly
  4. Folded block style (>): Converts single newlines to spaces, but preserves blank line paragraphs

But here’s the gotcha: trailing whitespace in plain-style strings gets silently dropped. So if you have:

message: "Line one
Line two"

The YAML parser sees: "Line one Line two" (single line, single space).

Even worse, GitHub Actions adds its own layer of processing. It evaluates $ expressions before parsing the YAML, which means you can end up with malformed YAML if the expression output contains quotes or special characters.

For multi-line git commit messages, we need an approach that survives both YAML parsing and GitHub Actions expression evaluation:

# CORRECT - literal block style preserves newlines
git commit -m "update RPM repository with latest packages" \
           -m "Automated update from workflow run $"

Alternatively, using multiple -m flags is even clearer, as each -m creates a new paragraph in the commit message:

git commit -m "chore: cleanup old packages" \
           -m "Automated cleanup from workflow run $" \
           -m "- Removed .deb packages older than 7 days" \
           -m "- Removed .rpm packages older than 7 days" \
           -m "- Updated repository metadata"

This creates a properly formatted commit message with a subject line and body paragraphs.

Troubleshooting Tip #4: Validating YAML in GitHub Actions workflows:

# Install yamllint locally
$ pip install yamllint

# Check your workflow file
$ yamllint .github/workflows/create-release.yml

# Common issues to watch for:
# - Trailing spaces (breaks literal blocks)
# - Inconsistent indentation (breaks structure)
# - Unquoted special characters (: { } [ ] , & * # ? | - < > = ! % @ \)

Commit message comparison (before and after fixing YAML):

Before (broken):

commit 1234567
Author: GitHub Actions
Date:   2025-11-20

    update RPM repository with latest packages Automated update from workflow run 123456

After (fixed):

commit 1234567
Author: GitHub Actions
Date:   2025-11-20

    update RPM repository with latest packages

    Automated update from workflow run 123456

    Changes:
    - Updated repository metadata
    - Added packages for version 2025.11.20

Notice the difference? The first version is a single-line message (hard to read in git logs). The second version has proper paragraphs, making it clear what changed and why.

Mistakes to Avoid #4: Don’t rely on whitespace in YAML to create formatting. Use explicit syntax (literal blocks with |, multiple -m flags, or shell features like heredocs) to ensure your intent survives the YAML parser.

Issue 6: Documentation Debt

The README Update

With all the technical issues fixed, I had one final problem: the documentation was outdated. The README still showed old installation instructions and didn’t document the new APT/RPM repositories.

I comprehensively updated the README to include:

  1. Architecture support table: Clear mapping between different architecture naming conventions
  2. APT repository instructions: Complete setup including GPG key import
  3. RPM repository instructions: Setup for Fedora/RHEL/Rocky/AlmaLinux
  4. GitHub Releases section: Manual package download instructions
  5. Version format documentation: Explaining the YYYY.MM.DD.BUILD_NUMBER scheme
  6. Repository structure documentation: Showing where packages are stored
  7. Distribution requirements: Minimum Debian/Fedora versions

Here’s an example of the new APT installation section:

#### Debian/Ubuntu (APT)

```bash
# Import GPG key
curl -fsSL https://github.com/gounthar/docker-for-riscv64/releases/download/gpg-key/gpg-public-key.asc | \
  sudo gpg --dearmor -o /usr/share/keyrings/openscad-archive-keyring.gpg

# Add repository
echo \"deb \[signed-by=/usr/share/keyrings/openscad-archive-keyring.gpg] https://gounthar.github.io/openscad stable main\" | \
  sudo tee /etc/apt/sources.list.d/openscad.list

# Update and install
sudo apt-get update
sudo apt-get install openscad

Supported Distributions:

  • Debian Trixie (13) and newer
  • Ubuntu 24.04 LTS and newer ```

This gives users a complete, copy-paste-ready installation experience with clear version requirements.

Testing the Complete System

After all fixes were in place, I tested the complete pipeline:

# Trigger a full build
git push origin multiplatform

# This starts the cascade:
# 1. Docker build workflow (3 architectures in parallel)
# 2. Package extraction workflows (Debian + RPM)
# 3. Repository update workflows (APT + RPM)
# 4. Release creation workflow

# Wait for completion, then test installation

Testing on each architecture:

# AMD64 (x86_64)
curl -fsSL https://github.com/gounthar/docker-for-riscv64/releases/download/gpg-key/gpg-public-key.asc | \
  sudo gpg --dearmor -o /usr/share/keyrings/openscad-archive-keyring.gpg
echo "deb [signed-by=/usr/share/keyrings/openscad-archive-keyring.gpg] https://gounthar.github.io/openscad stable main" | \
  sudo tee /etc/apt/sources.list.d/openscad.list
sudo apt-get update
sudo apt-get install openscad -y
openscad --version

# ARM64 (aarch64) - same process
# RISC-V64 - same process

# RPM testing
sudo rpm --import https://gounthar.github.io/openscad/rpm/RPM-GPG-KEY
sudo curl -L https://gounthar.github.io/openscad/rpm/openscad.repo \
  -o /etc/yum.repos.d/openscad.repo
sudo dnf install openscad -y
openscad --version

All installations succeeded, and concurrent workflows no longer conflicted.

Key Lessons Learned

1. Concurrency is Hard, Even in CI/CD

GitHub Actions makes it easy to parallelize work, but it doesn’t automatically handle coordination between workflows. When multiple workflows modify shared state (like a git branch), you need explicit concurrency control.

The combination of GitHub’s concurrency directive and the reset-and-restore pattern provides robust handling of concurrent updates—without complex locking.

2. RPM Spec Files Have Subtle Semantics

The difference between %dir /path/to/directory and /path/to/directory/ is easy to miss, but it completely changes RPM’s packaging behavior. Understanding the ownership model is crucial.

When in doubt, use:

  • %dir for shared directories you don’t populate
  • Paths with trailing slashes for directories you own completely
  • Glob patterns for shared directories where you only own some files

3. Match Build Environment to Dependencies

Your package dependencies must match what your binary is actually linked against. Tools like dpkg-shlibdeps (Debian) and rpm’s automatic dependency detection can help, but when working with pre-built binaries, manual verification is essential.

4. YAML is Surprisingly Complex

YAML’s string handling has many edge cases. For multi-line content in shell commands:

  • Use multiple -m flags for git commit messages
  • Use literal block style (|) when you need exact newline preservation
  • Test your YAML with yamllint to catch issues early

5. Idempotency and Retry Logic are Essential

Network operations fail. APIs have transient issues. Build robust systems by:

  • Making operations idempotent (can be safely repeated)
  • Adding retry logic with exponential backoff
  • Using features like --clobber to replace instead of failing on duplicates
  • Logging clearly so you can diagnose intermittent issues

6. Documentation is Part of the Product

The best automation is useless if users don’t know how to use it. Invest in clear, complete documentation that includes:

  • Copy-paste-ready commands
  • Clear version/distribution requirements
  • Architecture support matrix
  • Troubleshooting guidance

Frequently Asked Questions

How do I prevent concurrent GitHub Actions workflows from conflicting?

Use GitHub’s concurrency directive to control workflow execution:

concurrency:
  group: release-creation
  cancel-in-progress: false

Combined with the reset-and-restore pattern for git operations, this prevents race conditions when multiple workflows modify the same branch.

What is the reset-and-restore pattern in GitHub Actions?

The reset-and-restore pattern handles concurrent git conflicts by:

  1. Saving changes to a temporary directory
  2. Fetching and resetting to the latest remote state
  3. Restoring saved changes on top
  4. Retrying the push operation

This avoids merge conflicts in automated workflows.

How do I fix “unpackaged files found” errors in RPM builds?

Change %dir /path/ to /path/ (with trailing slash) in your RPM spec file’s %files section. The %dir directive only packages the directory entry, not its contents.

How do I synchronize multiple GitHub Actions workflows?

Use workflow creation timestamps to detect if workflows were triggered by the same build:

# Get creation times and compare within a sync window (e.g., 5 minutes)
DEB_TIME=$(gh api repos/$/actions/runs/${DEB_RUN} --jq '.created_at')
RPM_TIME=$(gh api repos/$/actions/runs/${RPM_RUN} --jq '.created_at')

Workflows created within your sync window are from the same build and can be safely combined.

Conclusion: Building Robust Multi-Architecture CI/CD Pipelines

Building a fully automated multi-architecture package distribution system for CI/CD pipelines is complex. It requires understanding:

  • Git coordination patterns for concurrent modifications
  • Package manager semantics (RPM, Debian) at a deep level
  • Dependency management across different distribution versions
  • GitHub Actions workflows and their concurrency model
  • Retry and idempotency patterns for robust automation

The reset-and-restore pattern proved particularly valuable. Instead of trying to merge concurrent changes (complex and error-prone), we save our changes, reset to the latest state, and reapply our changes on top. This works because our changes are additive and don’t conflict with each other - APT updates modify dists/, RPM updates modify rpm/, and both are independent.

The key insight is that concurrent workflows are inevitable in modern CI/CD. Rather than fighting them with complex locking, design your system to handle conflicts gracefully through idempotent operations and smart retry logic.

Now the OpenSCAD build infrastructure runs smoothly: three architectures, two package formats, automatic repository updates, and GitHub Releases - all working in harmony. The next time someone pushes a commit, packages are built, tested, and published across all architectures within an hour, with zero manual intervention.

And that’s the dream of automation: complexity managed, reliability achieved, and maintainers free to focus on actual development rather than packaging mechanics.

Beyond Package Management: Applying These Patterns to Other CI/CD Scenarios

The concurrency patterns and retry logic described here apply to many DevOps automation challenges:

  • Artifact management: Concurrent uploads to package registries
  • Container registry updates: Pushing multi-platform Docker images
  • Infrastructure as Code: Terraform state file conflicts
  • Continuous deployment: Coordinating deployments across environments

The reset-and-restore pattern is particularly valuable for any scenario involving concurrent modifications to shared state in continuous integration pipelines.

Further Reading
