Work with Armbian behind a corporate proxy

Work with Armbian behind a corporate proxy

1 htop 2 lscpu 3 htop 4 wget http://distribution.bbb3d.renderfarming.net/video/mp4/bbb_sunflower_1080p_30fps_normal.mp4 5 sudo ./remove-redsocks.sh 6 sudo ./redsocks.sh 7 ip a 8 sudo vi /etc/redsocks.conf 9 sudo reboot 10 htop 11 sudo armbian-config 12 htop 13 cat /etc/apt/apt.conf.d/10proxy 14 htop 15 history

[insert gif first-armbian-login]

[insert gif setup-apt-proxy] refaire, car j’ai la vraie IP dedans. sudo vi /etc/apt/apt.conf.d/10proxy

Acquire::http::Proxy “http://proxy-ip:proxy-port”;

sudo date -s “30 DEC 2019 17:21:00” export http_proxy=http://10.24.219.17:3128 export https_proxy=http://10.24.219.17:3128

[insert gif apt-update] sudo apt update sudo apt dist-upgrade

[insert gif redsocks] sudo apt install redsocks sudo vi /etc/redsocks.conf In the redsocks section, change the ip and port part so that it reflects your own proxy server configuration

    ip = 10.24.219.17;
    port = 3128;

[insert gif configure-redsocks]

Then list the ports that you’re interested in transferring to the proxy:

sudo iptables -t nat -N REDSOCKS

sudo iptables -t nat -A REDSOCKS -d 0.0.0.0/8 -j RETURN sudo iptables -t nat -A REDSOCKS -d 10.0.0.0/8 -j RETURN sudo iptables -t nat -A REDSOCKS -d 127.0.0.0/8 -j RETURN sudo iptables -t nat -A REDSOCKS -d 169.254.0.0/16 -j RETURN sudo iptables -t nat -A REDSOCKS -d 172.16.0.0/12 -j RETURN sudo iptables -t nat -A REDSOCKS -d 192.168.1.0/24 -j RETURN sudo iptables -t nat -A REDSOCKS -d 192.168.31.0/24 -j RETURN sudo iptables -t nat -A REDSOCKS -d 224.0.0.0/4 -j RETURN sudo iptables -t nat -A REDSOCKS -d 240.0.0.0/4 -j RETURN

sudo iptables -t nat -A REDSOCKS -p tcp -j REDIRECT –to-ports 12345

sudo iptables -t nat -A OUTPUT -p tcp –dport 443 -j REDSOCKS sudo iptables -t nat -A OUTPUT -p tcp –dport 1935 -j REDSOCKS sudo iptables -t nat -A OUTPUT -p tcp –dport 80 -j REDSOCKS sudo iptables -t nat -A OUTPUT -p tcp –dport 21 -j REDSOCKS

sudo iptables -t nat -A PREROUTING -p tcp –dport 443 -j REDSOCKS sudo iptables -t nat -A PREROUTING -p tcp –dport 1935 -j REDSOCKS sudo iptables -t nat -A PREROUTING -p tcp –dport 80 -j REDSOCKS sudo iptables -t nat -A PREROUTING -p tcp –dport 21 -j REDSOCKS

redsocks { /* local_ip' defaults to 127.0.0.1 for security reasons, * use 0.0.0.0 if you want to listen on every interface. * local_*’ are used as port to redirect to. */ local_ip = 127.0.0.1; local_port = 12345; … }

update-alternatives –set iptables /usr/sbin/iptables-legacy update-alternatives –set ip6tables /usr/sbin/ip6tables-legacy update-alternatives –set arptables /usr/sbin/arptables-legacy update-alternatives –set ebtables /usr/sbin/ebtables-legacy

Comme a ne fonctionne pas bien, je suis cette doc.

iptables-save > save.txt

iptables-restore-translate -f save.txt

iptables-restore-translate -f save.txt > ruleset.nft

apt install nftables

nft -f ruleset.nft
update-alternatives --set iptables /usr/sbin/iptables-nft
update-alternatives --set ip6tables /usr/sbin/ip6tables-nft
update-alternatives: using /usr/sbin/ip6tables-nft to provide /usr/sbin/ip6tables (ip6tables) in manual mode
update-alternatives --set arptables /usr/sbin/arptables-nft
update-alternatives --set ebtables /usr/sbin/ebtables-nft

a ne fonctionne toujours pas. Ce bug est sans doute lire/suivre.

echo “heartbeat” > /sys/class/leds/orangepi:red:status/trigger echo “mmc0” > /sys/class/leds/orangepi:green:pwr/trigger

cd ~/ffmpeg_sources

wget https://github.com/xbmc/FFmpeg/archive/4.0.4-Leia-18.4.tar.gz wget https://raw.githubusercontent.com/LibreELEC/LibreELEC.tv/master/packages/multimedia/ffmpeg/patches/ffmpeg-99.1001-Call-get_format-to-fix-an-issue-with-MMAL-ren.patch sudo apt-get install -y libtool libdrm-dev libudev-dev libvorbis-dev

instructions found there: https://forum.armbian.com/topic/12228-not-enough-memory-to-compile-on-orangepi-zero/?do=findComment&comment=89609

sudo fallocate -l 8G /swapfile Allocate 8GB for swapfile sudo chmod 600 /swapfile Give the correct rights for the swapfile sudo mkswap /swapfile Make it a swapfile sudo swapon /swapfile Turn on the swapfile sudo nano /etc/fstab Open fstab and add the line …

/swapfile swap swap defaults 0 0

armbianmonitor -m

cd ~/ffmpeg_sources wget http://deb.debian.org/debian/pool/main/d/debhelper/debhelper_12.7.1.tar.xz xz -d debhelper_12.7.1.tar.xz && tar -xvf debhelper_12.7.1.tar && rm debhelper_12.7.1.tar cd debhelper/ sudo apt install -y po4a sudo -E dpkg-buildpackage -us -uc sudo apt –fix-broken install sudo dpkg -i ../libdebhelper-perl_12.7.1_all.deb && sudo apt install dwz && sudo dpkg -i ../debhelper_12.7.1_all.deb

cd ~/ffmpeg_sources wget -O fdk-aac.tar.gz https://github.com/mstorsjo/fdk-aac/tarball/master tar xzvf fdk-aac.tar.gz cd mstorsjo-fdk-aac* autoreconf -fiv ./configure –prefix=”$HOME/bin” –disable-shared make -j1 make -j1 install make -j1 distclean

cd ~/ffmpeg_sources git clone https://chromium.googlesource.com/webm/libvpx cd libvpx ./configure make -j1 sudo make install

cd ~/ffmpeg_sources wget http://deb.debian.org/debian/pool/main/libm/libmysofa/libmysofa_0.8~dfsg0.orig.tar.xz xz -d libmysofa_0.8~dfsg0.orig.tar.xz && tar -xvf libmysofa_0.8~dfsg0.orig.tar && rm libmysofa_0.8~dfsg0.orig.tar cd libmysofa-0.8/ && wget http://deb.debian.org/debian/pool/main/libm/libmysofa/libmysofa_0.8~dfsg0-1.debian.tar.xz xz -d libmysofa_0.8~dfsg0-1.debian.tar.xz && tar -xvf libmysofa_0.8~dfsg0-1.debian.tar && rm libmysofa_0.8~dfsg0-1.debian.tar sudo apt install -y dh-exec cmake libcunit1-dev zlib1g-dev libz-dev wget http://deb.debian.org/debian/pool/main/libm/libmysofa/libmysofa_0.8~dfsg0.orig.tar.xz && mv libmysofa_0.8~dfsg0.orig.tar.xz .. sudo apt install -y debhelper-compat dh-exec cmake libcunit1-dev

sudo -E dpkg-buildpackage -us -uc sudo dpkg -i ../libmysofa-utils_0.8~dfsg0-1_armhf.deb ../libmysofa-dev_0.8~dfsg0-1_armhf.deb ../libmysofa0_0.8~dfsg0-1_armhf.deb

cd ~/ffmpeg_sources wget http://deb.debian.org/debian/pool/main/libv/libvidstab/libvidstab_1.1.0.orig.tar.gz tar -xvzf libvidstab_1.1.0.orig.tar.gz cd vid.stab-1.1.0/ && wget http://deb.debian.org/debian/pool/main/libv/libvidstab/libvidstab_1.1.0-2.debian.tar.xz xz -d libvidstab_1.1.0-2.debian.tar.xz && tar -xvf libvidstab_1.1.0-2.debian.tar && rm libvidstab_1.1.0-2.debian.tar sudo -E dpkg-buildpackage -us -uc sudo dpkg -i ../libvidstab1.1_1.1.0-2_armhf.deb ../libvidstab-dev_1.1.0-2_armhf.deb

cd ~/ffmpeg_sources wget http://www.nasm.us/pub/nasm/releasebuilds/2.14rc0/nasm-2.14rc0.tar.gz tar xzvf nasm-2.14rc0.tar.gz cd nasm-2.14rc0 ./configure –prefix=”$HOME/bin” –bindir=”$HOME/bin” make -j2 VERBOSE=1 make -j2 install make -j$(nproc) distclean

I had a problem with nasm ./include/nasmlib.h:195:1: error: ‘pure’ attribute on function returning ‘void’ [-Werror=attributes] because of gcc’s 8.2 version. https://bugzilla.nasm.us/show_bug.cgi?id=3392461 => rebuild gcc?

cd ~/ffmpeg_sources git clone http://git.videolan.org/git/x264.git -b stable cd x264/ export CFLAGS=”-mfpu=neon” PATH=”$HOME/bin:$PATH” ./configure –prefix=”$HOME/bin” –bindir=”$HOME/bin” –enable-pic –enable-static –disable-cli –disable-asm –host=arm-linux –disable-opencl PATH=”$HOME/bin:$PATH” make -j2 VERBOSE=1 make -j2 install VERBOSE=1 make -j$(nproc) distclean

cd ~/ffmpeg_sources sudo apt install -y python3-sphinx wget http://deb.debian.org/debian/pool/main/x/x265/x265_3.2.orig.tar.gz tar -xvzf x265_3.2.orig.tar.gz cd x265_3.2/ wget http://deb.debian.org/debian/pool/main/x/x265/x265_3.2-2.debian.tar.xz xz -d x265_3.2-2.debian.tar.xz && tar -xvf x265_3.2-2.debian.tar && rm x265_3.2-2.debian.tar sudo -E dpkg-buildpackage -us -uc sudo dpkg -i ../libx265-dev_3.2-2_armhf.deb ../libx265-179-dbgsym_3.2-2_armhf.deb ../libx265-179_3.2-2_armhf.deb ../libx265-doc_3.2-2_all.deb

cd ~/ffmpeg_sources/FFmpeg-4.0.4-Leia-18.4/ sudo apt install -y libgl1-mesa-dev PATH=”$HOME/bin:$PATH” PKG_CONFIG_PATH=”$HOME/bin/lib/pkgconfig:/usr/local/lib/pkgconfig” ./configure –pkg-config-flags=”–static” –prefix=”$HOME/bin” –extra-cflags=”-I$HOME/bin/include” –extra-ldflags=”-L$HOME/bin/lib” –extra-cflags=”-I/usr/local/include” –extra-ldflags=”-L/usr/local/lib” –bindir=”$HOME/bin” –enable-debug=3 –enable-vaapi –enable-libvorbis –enable-libvpx –disable-debug –enable-gpl –cpu=native –enable-opengl –enable-libfdk-aac –enable-libx264 –enable-libx265 –extra-libs=-lpthread –enable-nonfree –arch=arm

ERROR: vaapi requested but not found sudo apt install -y libva-dev libdrm-dev

PATH=”$HOME/bin:$PATH” PKG_CONFIG_PATH=”$HOME/bin/lib/pkgconfig:/usr/local/lib/pkgconfig” ./configure –pkg-config-flags=”–static” –prefix=”$HOME/bin” –extra-cflags=”-I$HOME/bin/include” –extra-ldflags=”-L$HOME/bin/lib” –extra-cflags=”-I/usr/local/include” –extra-ldflags=”-L/usr/local/lib” –bindir=”$HOME/bin” –enable-debug=3 –enable-vaapi –enable-libvorbis –enable-libvpx –disable-debug –enable-gpl –cpu=native –enable-opengl –enable-libfdk-aac –enable-libx264 –enable-libx265 –extra-libs=-lpthread –enable-nonfree –arch=arm now works

make made it to the end. Hurray!

Now, let’s apply the patches found there: https://github.com/LibreELEC/LibreELEC.tv/tree/master/packages/multimedia/ffmpeg/patches

once done, find the linux kernel patches there: https://github.com/LibreELEC/LibreELEC.tv/tree/master/projects/Allwinner/patches/linux after reading https://forum.armbian.com/topic/11551-4kp30-video-on-orange-pi-lite-and-mainline-hardware-acceleration/?do=findComment&comment=88617

cat >patche patch -p1 < patche

cd /usr/src/linux-source-5.3.9-current-sunxi64 mv ../linux-source-5.3.9-sunxi64.tar.xz . sudo -E xz -d linux-source-5.3.9-sunxi64.tar.xz && sudo tar -xf linux-source-5.3.9-sunxi64.tar && sudo rm linux-source-5.3.9-sunxi64.tar https://www.cyberciti.biz/linux-news/linux-kernel-5-3-released-and-here-is-how-to-install-it/ sudo apt-get install -y build-essential libncurses-dev bison flex libssl-dev libelf-dev
